ONE PLUS 8 Specifications

Dimensions

• Height：160.2 mm

• Width：72.9 mm

• Thickness：8.0 mm

• Weight：180g

Display

Parameters

• Size: 6.55 inches(The corners of the screen are within a standard rectangle. Measured diagonally, the screen size is 6.55 inches in the full rectangle and 6.34 inches accounting for the rounded corners.)

• Resolution: 2400 x 1080 pixels 402 ppi

• Aspect Ratio: 20:9

• Type: Fluid AMOLED

• Support sRGB, Display P3

• Cover Glass: 3D Corning® Gorilla® Glass

Features

• Reading Mode

• Night Mode

• Vibrant Color Effect

Performance

• Operating System: OxygenOS based on Android™ 10

• CPU: Qualcomm® Snapdragon™865

• 5G Chipset: X55

• GPU: Adreno 650

• RAM: 8GB/12GB LPDDR4X

• Storage: 128GB/256GB UFS 3.0 2-LANE

• Battery: 4300 mAh (non-removable)

• Warp Charge 30T Fast Charging (5V/6A)

Camera

Rear camera - Main

• Sensor: Sony IMX586

• Megapixels: 48

• Pixel Size: 0.8µm

• Lens Quantity: 6P

• OIS: Yes

• EIS: Yes

• InAperture: f/1.75

Macro Lens

• Megapixels: 2

• Pixel Size: 1.75µm

• Aperture: f/2.4

Ultra Wide Angle Lens

• Megapixels: 16

• Aperture: f/2.2

• Field of View: 116°

Flash

• Dual LED Flash

Optical Zoom

• No（Support in sensor zoom 2X）

Autofocus

• Multi Autofocus (PDAF+CAF)

Video

• 4K video at 30/60 fps

• 1080P video at 30/60 fps

• Super Slow Motion: 1080p video at 240 fps, 720p video at 480 fps

• Time-Lapse 1080P 30fps, 4k 30fps

• Video Editor

Features

• CINE aspect ratio video recording, UltraShot HDR, Nightscape, Micro , Portrait, Pro Mode, Panorama, Cat&dog face detection&focus, AI Scene Detection, RAW Image

Front Camera

• Sensor: Sony IMX471

• Megapixels: 16

• Pixel Size: 1.0 µm

• EIS: Yes

• Autofocus: Fixed Focus

• Aperture: f/2.45

Video

• 1080P video at 30fps

• Time-Lapse

Features

• Face Unlock, HDR, Screen Flash, Face Retouching

Connectivity

LTE/LTE-A

• 4×4 MIMO, Supports up to DL Cat 18/UL Cat 13(1.2Gbps /150Mbps), depending on carrier support

Band

• GSM：GSM850、GSM900、GSM1800、GSM1900

• WCDMA：B1、B2、B4、B5、B8、B9、B19

• CDMA：BC0

• LTE-FDD：B1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 66

• LTE-TDD：B34, 38, 39, 40, 41, 42, 46

• 5G：n1, n3, n7, n28, n78

• MIMO：LTE：B1, 3, 7, 38, 40, 41 NR: n1, n3, n7, n78

• （Note:Actual network and frequency band usage depends on local operator deployment. N1, 3,7,28 will be supported later through upgrades）

Wi-Fi

• IEEE 802.11 a/b/g/n/ac/ax, 2.4G+5G, 2x2 MIMO

Bluetooth

• Bluetooth 5.1, support aptX & aptX HD & LDAC & AAC & SBC

NFC

• NFC enabled

Positioning

• GPS (L1+L5 Dual Band), GLONASS, Galileo (E1+E5a Dual Band), Beidou, A-GPS

Check carrier compatibility

Sensors

• In-display Fingerprint Sensor

• Accelerometer

• Electronic Compass

• Gyroscope

• Ambient Light Sensor

• Proximity Sensor

• Sensor Core

Ports

• USB 3.1 GEN1

• Type-C

• Support standard Type-C earphone

• Dual nano-SIM slot

Buttons

• Gestures and on-screen navigation support

• Alert Slider

Audio

• Dual Stereo Speakers

• Noise cancellation support

• Dolby Atmos®

Multimedia

Audio Supported Formats

• Playback: MP3, AAC, AAC+, WMA, AMR-NB, AMR-WB, WAV, FLAC, APE, OGG, MID, M4A, IMY, AC3, EAC3, EAC3-JOC, AC4

• Recording: WAV, AAC, AMR

Video Supported Formats

• Playback: MKV, MOV, MP4, H.265(HEVC), AVI, WMV, TS, 3GP, FLV, WEBM

• Recording: MP4

Image Supported Formats

• Playback: JPEG, PNG, BMP, GIF, WEB, HEIF, HEIC, RAW

• Output: JPEG, DNG

In The Box

• OnePlus 8

• Warp Charge 30 Power Adapter

• Warp Type-C Cable (Support USB 2.0)

• Quick Start Guide

• Welcome Letter

• Safety Information and Warranty Card

• LOGO Sticker

• Case

• Screen Protector

• SIM Tray Ejector
